The Dragon Meets the World
DragonO²
The Body That Inhabits Space
The first commercial generation In our genetic history.
The proven standard.
DragonO² is a body that exists in space the way a living organism does, three-dimensional, transparent, modular, and continuously alive. Each of its neurons decodes encoded video signal transmitted through a single copper cable and emits light at an exact coordinate in three dimensions. Every pixel maps directly to a voxel. The body occupies space without obstructing it. It inhabits architecture without altering it.
Built to be present, precisely, for as long as the space requires.
Hardware
Body
The most reliable volumetric system in the world. Refined over a decade of installations and experiences across continents.
Every structural decision tested and engineered for extreme conditions. Durability is not a feature, it's an essential part of the architecture.
High Endurance
10-15 mins Replacement
replacement
2.5 Organic Pitch
Definition, higher pitch in organic matrix
4 Removable PCBs
40% Enhanced Conductivity
50% Lighter Base
Fault Isolation
PCB System
A More Efficient Body
Increased Performance
Maintenance Efficiency
Rapid component replacement
10-15 mins
Enhanced efficiency
Integrated circuits
Super modularity
4 Independent removable PCBs
Maintenance is an essential part of the installations. Especially the long-term ones. Can you imagine reducing the replacement time of a PCB from several hours to 10 to 15 minutes? This is the huge breakthrough in DragonO2.
The latest version has four independent removable PCBs for each module. A unique design that allows parts to be replaced and adjusted in a matter of minutes. Something that was previously impossible. This allows us to be prepared for the worst scenarios where human factors and environmental conditions can be extreme and unpredictable.
Organic System
A matrix closer to the way real biological three-dimensional structures are generated.
Higher
Resolution
Shorter
Pitch
String Pitch
5 CM
Organic pitch
2.5 CM
In conventional video displays, pixels are arranged in rows and columns (x and y axis) which is effective for 2-dimensions.
Layered to create a simple cubic 3D display, a Z axis is added.
In the Dragon O, the cubic (x,y,z) format, is insufficient leaving empty spaces between the voxels (pixels in 3D).
To make it up for the lack of information in conventional formats. We have created the Voxel organic distribution system.
Using algorithms, we redistribute Voxels so that they fill the empty spaces.
The result is a much higher resolution / smaller pitch, using the same number of LEDs.
Strings
A More Aesthetic Body
Greater
Energy Diffussion
Better
Data Transmission
Improved
Cable Resistance
Increased Accuracy
Higher Resolution
40% more efficiency in data and energy transmission. 70% more flexibility. These are just some of the data for these new strings. But the most important factor is the improvement in resolution and image quality. The new strings line up perfectly and almost magically hold their verticality. The incessant search for new materials and better quality finishes has made this possible.
Strings
Light and energy flows through the Dragon's veins
The strings are the center of our technology and the essence of the Dragon. Simple tiny copper wires transformed into torrents of light and energy in coordination and control. The energy is transformed into volumes of light throughout the strings.
Cable composition
Isolation coating
Size
Connector
Base
Cable tensioner
Coating color
Max weight tolerance
Universal Replacement Automatic Detection
Smart auto-addressing strings
If one of the strings fails, the rest of the strings keep working.
The strings and voxels automatically identify their position when replaced. The replacement operation is performed in seconds and can be done even with the Dragon running and connected.
Our Patented Technology
The Neuronal LED
Faster
Micro Processor
Flawless
Color Balance
Higher
Framerate
More Efficiency
Self-Addressing
The DragonO Neuronal System is a unique patented revolutionary technology where information travels through an electrical current encrypted in binary code.
Each micro processor interprets this information and translates it into RGB light pulses with an unparalelled range of brightness and color quality.
Each Neuron interprets the information independently. The conjunction of all neurons conforms the tridimensional image.
Higher Framerate
Faster microprocessor
Flawless color balance
self addressing
Play To Discover
Gravity
Dragon's best friend
The force of gravity is usually a challenge for large installations. In Dragon O, gravity plays in our favor.
Gravity working on the Dragon's transparent polycarbonate floor and specially designed “Shock Absorber” system keeps the strings vertically and horizontally aligned and under tension - ensuring precise voxel placement.
%20(1).jpg)
Acrylic Board
A Lighter Body
Lighter
50% Less Weight
Thiner
50% Thickness Reduction
Transparency
50% More Transparent
Easier & Streamlined
Transportation
The acrylic base is one of the design factors that identifies the Dragon. Now this base has reduced its weight and thickness by half! This substantially reduces the weight of the device in general, making it more transportable, easier to install and with a higher level of transparency in the base. A beautiful Dragon from head to toes.
Modular Frames
Solid / Safe / Ease of Assembly
Module size
50cm x 50cm
Pitch
2.5cm Organic
Number of Strings
100 / Module
Strings Standard length
3m
Strings maximum length
5m
Voxels in standard module
6,000 Voxels
We have adapted the engineering and design of the best modular 2D LED technology and created an assembly system familiar to A/V integrators that meets professional standards.
Any installation technician with average training will understand the assembly immediately.
A modular anatomy that can be assembled in nearly infinite ways
DragonO² consists of modules that are assembled together to create a wide variety of shapes and configurations
9 MODULES
12 MODULES
16 MODULES
36 MODULES
-poster-00001.jpg)
Packaging & Installation
An ultralight piece of art ready for hard work
Only 4% of the volume of our system is made of rigid material. The rest is made up of our ultra-light and ultra-flexible LED strings.
1.BOX
Each module comes in an individual box
2. Wrap system
Strings come attached in a wrap system that keeps them aligned and disentangled
3. Lifting
The modules should then be assembled, rigged, and lifted
4. Alignment
After assembling, strings are unwrapped and aligned. Make sure they are all attached to the acrylic board through the silicon shock absorbers
Rigging
A piece of art ready for hard work
Behind the beauty and aesthetics of Dragon O is a solid, strong and safe structure.
The rigging system is adapted for the most extreme conditions and security demands of Show Business and Architecture.
Dragon top frame support
Composition
Die casting aluminium
Power supply input output
External power bi-directional power connector
Ethernet input output
External bi-directional video connector
Module interconnection
Metal solid lock
Rigging / fixation
Standard LED metal cabinet accesories
Locking points per module
Module mounting type
Standard LED power mounting
Module mounting size
50cm x 50cm x 12cm
Average power consumption
90W
Peak power consumption
180W
Weight
∼17kg
.jpg)
A Stack of Processing Systems & Tools
Developed To Model Volumetric Simulations of Physical Environments
A system that operates with the most powerful and advanced set of software tools created exclusively for DragonO² optimal performance.
Software
Mind
DragonO² is the proven software architecture that established the global standard for volumetric intelligence and made volumetric light a viable commercial proposition.
Every volumetric system in the world hits the same wall: DMX. Universe limits. Translation layers. Protocol ceilings. LedPulse broke through it with a patented direct video architecture that maps every pixel to its voxel in real time. One computer. No intermediary.
We designed a rendering and simulation pipeline, providing a mature, industrial-grade foundation that balances real-time performance with absolute reliability. Full compatibility with the LYRA cognitive layer.
The reference standard. A decade later, still unreplicated.
Fully Automated Rendering
LIVE pixel-to-voxel transmission
High-Fidelity Simulation
Ecosystem Ready
Mapping the End-to-End Pipeline
LYRA AI compatible
PROME3 Generator
the first fully automatic volumetric LED render engine
A proprietary tool designed exclusively by LedPulse. It enables creators to visualize volumetric content and transmit it in real time, directly into the installation, bridging the gap between digital design and physical light.
REAL-TIME VISUALIZATION
Visualize and transmit volumetric content directly into the installation
3D FILE IMPORT
Compatible with C4D, Blender, Houdini, 3DS Max and more
STANDARD VIDEO EXPORT
Render into standard video file formats
DMF FILE GENERATION
Generate native DMF files for DragonO²
VOLUMETRIC EDITING
Edit content with full volumetric capabilities
REAL-TIME TEXTURING
Texture, skin, and light editing in real time
Unreal Simulator
Simulate your installation voxel by voxel. What you design is exactly what the Dragon displays.
No more guessing what the installation will look like. Our Unreal Engine simulator renders every Dragon configuration voxel by voxel, letting you navigate around the full volume in real-time.
Place it inside any environment with high-fidelity lighting and scale.
The Simulator can be fully standalone executable in Windows, and it can also be seamlessly integrated into any Unreal Engine project.
ORGANIC SIMULATION
Voxel-by-voxel volumetric rendering
ENVIRONMENT PLACEMENT
Shape and position your installation in any space
FULL RANGE INTEGRATION
Compatible across all Dragon configurations
STAGE MONITORING
Work in tandem with all connected devices
EXTERNAL SYNC
Integrate and synchronize DMX, Kinect, 2D screens and more
TouchDesigner +
Rendering Engines
A new medium, native to the tools creators already use worldwide
The Dragon rendering engine opens the volumetric format to a global community of digital creators.
Purpose-built patch for TouchDesigner give artists direct access to the Dragon’s three-dimensional canvas — no translation layers, no protocol workarounds.
VOLUMETRIC RENDERING
Native three-dimensional content pipeline
REAL-TIME OUTPUT
Render and transmit directly to the Dragon
3D FILE IMPORT
Compatible with standard 3D file formats
SENSOR INTEGRATION
Connect DMX, Cameras, Microphones, Noitom, Kinect, and more
VJ + Media Player
PLAY, PERFORM AND EXPERIMENT WITH VOLUMETRIC LIGHT
Cast volumetric content in real time or through the simulator using any media server — from VJ platforms like Resolume to standard video players.
The DMF format unlocks the full depth of three-dimensional playback, letting you perform, sequence, and experiment with volumetric light on the tools you already know.
Fully compatible with Ventuz systems.
UNIVERSAL PLAYBACK
Compatible with Resolume, Ventuz and standard video players
DMF FORMAT
Native volumetric file format for full 3D playback
REAL-TIME CASTING
Stream content live or play through the simulator
MEDIA SERVER READY
Integrates with your existing production workflow
LYRA AI
The cognition of the Dragon
The intelligence that gives DragonO² its behavior. LYRA reads the environment, interprets what it finds, and shapes how the body responds through light, movement, and spatial transformation. Perception, cognition, and expression operating as a single continuous cycle.
DragonO² is the body that brought the Dragon into the world. LYRA is what gives it a mind inside that world.
PERCEPTION SYSTEM
Real-time sensing of presence, movement, attention, and collective behavior
RATIONAL ANALYSIS
AI interprets the environment beyond parametric tracking, responding to what people are actually doing
BEHAVIORAL MEMORY
The system compares current states against historical data to understand intent, emotion and energy
ORIGIN CELL
The person with the highest attention coefficient becomes the dynamic starting point of the content sequence
Sculpted in Three-Dimensions
The Content That Generates Emotion And Connection
A system that operates with the most powerful and advanced set of software tools created exclusively for DragonO² optimal performance.
Content
Soul
The soul of the Dragon is the content that generates emotion and connection.
Content for Dragon O², is sculpted in three dimensions, occupying real physical space.We treat content creation as its own discipline. The soul is the emergent behavior, the stories sculpted in light.
Every piece, made for a medium that didn’t exist before we built it.
